特征与用途Features:
·全钽外壳、气密封、圆柱形、同向引出、有极性。
Tantalum case encapsulation, Hermetically Sealed, Cylindrical，Axial-lead，Heteropolarity;
·产品是钽电解电容器和电化学电容器组成的混合电容器，体积小、储存能量大。
Commingled by Electrolytic Tantalum Capacitor and Electrochemical Capacitor, Small in size, Super Capacitance. This series products is firstly witnessed at home;
·电性能优良稳定、可靠性高、寿命长、单位体积内能量密度大、容量比THC1型大。
Stable in Electrical Performances, High Reliability, Long life-span, Maximum in the Density of Capacitance and Energy, Nominal Capacitance is higher than THC1 series;
·在能量转换电路、功率脉冲电路中可以起电池作用，为电路提供贮能、断电延时等功能。
Built-in as battery in Energy-conversed-circuit &Power-pulsed-circuit, functioned as filtering, storage energy, blackout& delaying;
·订货格式：THC2-50V24000μF-M：100只（A）
Ordering Information: THC2-50V24000μF-M：100 pcs（A）
主要技术性能Technical Performances:
使用温度范围：-55℃~125℃（+125℃时，施加类别电压使用）
Operating Temperature Range: -55℃~+125℃(when ＞+125℃， with rated voltage derating)
存储环境温度：-62℃~+130℃
Storage Temperature Range: -62℃～+130℃
电容量允差：K级：±10%，M级：±20%，Q级：-10%~+30%
Capacitance Tolerance: K级：±10%，M级：±20%，Q级：-10%~+30%;
电性能：见表
Electrical Performances: See tables
表1 额定电压、类别电压、浪涌电压、标称电容量和主要特性
Table1 Electrical Characteristics:
|
额定
电压
(V)
Rated Voltage
(V)
|
类别
电压
(V)
Category Voltage
(V)
|
浪涌
电压
(V)
Surge Voltage(V)
|
标称
电容量
(μF)
Nominal
Capacitance(μF)
|
tgδ
(%)
|
ESR
(Ω)
|
