CC40

您当前所在的位置:首 页>产品分类> CC40



特征与应用:
·方形,圆形引线径向引出,环氧树脂涂覆包封,适合于印刷线路板插装;
Square Shape,Radial lead, Epoxy-Coated, Suit for thru- hole assembly;
·介质为Ⅰ类瓷介,频率特性好,电容量稳定性高;
Class ⅠCeramic Dielectric,Excellent at frequency characteristics, Stable in Capacitor Capacitance;
·产品100%进行温度冲击和高温电负荷筛选;
Have experienced 100% Thermal Shock & High-Temperature Electron-Load Screening;
·适用于各类军用电子设备中的谐振回路、耦合电路及要求低损耗、容值稳定性高和绝缘电阻高的电路中;
Applying in kinds of Resonance Circuit, Coupling Circuit, and many circuits which needs Low ESR, High reliable capacitance, High Insulation resistance.

主要性能指标及执行标准
Main Characteristics
使用温度范围:-55℃~125℃;
Operating Temperature Range: -55℃~125℃;
温度系数 : CG: 0±30ppm/℃、CH: 0±60ppm/℃;
Temperature Coefficient: CG: 0±30ppm/℃、CH: 0±60ppm/℃;
电容量漂移:(-0.2%~+0.2%)或(-0.05pF~+0.05 pF)取较大者;
Capacitance Variability: (-0.2%~+0.2%) or(-0.05pF~+0.05 pF)Choose the greater one;
损耗角正切值:DF≤0.15%;
DF(tgδ):DF≤0.15%;
绝缘电阻:在25℃,不低于100000MΩ或1000MΩ·μF取较小者;
Insulation Resistance: at 25℃, not lower than 100000MΩ或1000MΩ·μF.(Choose the smaller one;)
介质耐压:2.5UR
Dielectric Withstanding Voltage:2.5UR
执行企军标:QJ/PWV403-2010;
Executive Company Standard:QJ/PWV403-2010;

订货示例
Ordering Information

S-
CC40
SR20
CG
101
J
500
A
B
质量等级
Quality Grade
型号
Series
外形尺寸
Dimensions
温度系数
Temperatrue
Coefficient
